LUXEON Rebel Color 系列具有領先的光輸出、顏色穩定度、光通密度以及清晰飽和的顏色。這些彩色 LED 適合大量照明、信令、標志及娛樂應用。所有 LUXEON Rebel Color 發光器都具有打造卓越、高質量燈具所需的質量、可靠性、流明維護和制造簡易性。LUXEON Rebel Color 發光器能為設計師提供無限的色彩選擇，為所有照明項目增添趣致、維度及活力。
Product performance of LUXEON Rebel Color Line at test conditions.
| COLOR |
DOMINANT[1,2] OR PEAK[2] WAVELENGTH (nm) |
LUMINOUS FLUX [1,3](lm) OR RADIOMETRIC POWER[3] (mW) |
TEST CURRENT (MA) | PART NUMBER | ||
|---|---|---|---|---|---|---|
| MINIMUM | MAXIMUM | MINIMUM | TYPICAL | |||
| Far Red | 720 | 750 | 210 | 260 | 350 | LXML-PF01 |
| Deep Red | 650 | 670 | 270 | 360 | 350 | LXM3-PD01 |
| Red | 620 | 645 | 60 | 62 | 350 | LXM2-PD01-0060 |
| 620 | 645 | 50 | 53 | 350 | LXM2-PD01-0050 | |
| 620 | 645 | 40 | 48 | 350 | LXM2-PD01-0040 | |
| 620 | 645 | 50 | 52 | 350 | LXML-PD01-0050 | |
| 620 | 645 | 40 | 46 | 350 | LXML-PD01-0040 | |
| 620 | 645 | 30 | 38 | 350 | LXML-PD01-0030 | |
| 620 | 645 | 50 | 64 | 350 | LXM5-PD01 | |
| Red-Orange | 610 | 620 | 70 | 72 | 350 | LXM2-PH01-0070 |
| 610 | 620 | 60 | 67 | 350 | LXM2-PH01-0060 | |
| 610 | 620 | 60 | 62 | 350 | LXML-PH01-0060 | |
| 610 | 620 | 50 | 56 | 350 | LXML-PH01-0050 | |
| 610 | 620 | 50 | 90 | 350 | LXM5-PH01 | |
| PC Amber | 594 | 604 | 80 | 110 | 350 | LXM2-PL01-0000 |
| Amber | 585 | 595 | 60 | 61 | 350 | LXML-PL01-0060 |
| 585 | 595 | 50 | 54 | 350 | LXML-PL01-0050 | |
| 585 | 595 | 40 | 48 | 350 | LXML-PL01-0040 | |
| 585 | 595 | 30 | 38 | 350 | LXML-PL01-0030 | |
| 585 | 595 | 50 | 74 | 350 | LXM5-PL01 | |
| Lime | 566 | 569 | 140 | 184 | 350 | LXML-PX02-0000 |
| Green | 520 | 540 | 100 | 102 | 350 | LXML-PM01-0100 |
| 520 | 540 | 90 | 95 | 350 | LXML-PM01-0090 | |
| 520 | 540 | 80 | 88 | 350 | LXML-PM01-0080 | |
| 520 | 540 | 70 | 79 | 350 | LXML-PM01-0070 | |
| Cyan | 490 | 515 | 80 | 83 | 350 | LXML-PE01-0080 |
| 490 | 515 | 70 | 76 | 350 | LXML-PE01-0070 | |
| 490 | 515 | 60 | 67 | 350 | LXML-PE01-0060 | |
| Blue | 460 | 485 | 40 | 41 | 350 | LXML-PB01-0040 |
| 460 | 485 | 30 | 35 | 350 | LXML-PB01-0030 | |
| 460 | 485 | 23 | 28 | 350 | LXML-PB01-0023 | |
| 460 | 485 | 18 | 22 | 350 | LXML-PB01-0018 | |
| 460 | 485 | 50 | 74 | 350 | LXML-PB02 | |
| Royal Blue | 440 | 460 | 500 | 520 | 350 | LXML-PR01-0500 |
| 440 | 460 | 1100 | 1120 | 700 | LXML-PR02-1100 | |
| 440 | 460 | 1050 | 1070 | 700 | LXML-PR02-1050 | |
| 440 | 460 | 1000 | 1030 | 700 | LXML-PR02-1000 | |
| 440 | 460 | 950 | 970 | 700 | LXML-PR02-0950 | |
| 440 | 460 | 900 | 940 | 700 | LXML-PR02-0900 | |
| 440 | 460 | 800 | 890 | 700 | LXML-PR02-0800 | |
| 440 | 460 | 900 | 1030 | 700 | LXML-PR02-A900[4] | |
 |
|
